E-Plane Waveguide Bends
Precision-engineered E-plane waveguide bends from WR-03 to WR-28. 90-degree bends with low insertion loss. Gold-plated OFHC copper. Made in the USA.
Select an E-Plane Bend
Signal Routing in the E-Field Plane
RF Essentials E-plane waveguide bends are precision-machined components that redirect microwave and millimeter-wave signals by curving along the wider dimension of the rectangular waveguide. This bending plane corresponds to the electric field orientation, making E-plane bends essential for signal routing in compact RF assemblies.
Available in standard 90-degree configurations across all WR sizes from WR-28 through WR-03, these bends maintain superior VSWR and minimal insertion loss. Each bend is manufactured from OFHC copper with gold plating for long-term reliability.
Key Features
E-Plane Geometry
Bend follows the wider dimension (E-field plane) of the waveguide for optimal signal routing in vertical orientations.
Low Insertion Loss
Precision-machined interior surfaces minimize signal degradation through the bend radius.
Consistent VSWR
Engineered for excellent return loss performance across the full operating bandwidth.
Materials & Finish
- 01Waveguide Body
Oxygen-free high conductivity (OFHC) copper for maximum signal performance and minimal loss. - 02Flanges
Precision-machined brass flanges with standard MIL-DTL-3922 patterns for universal compatibility. - 03Surface Finish
Gold plating for superior corrosion resistance, environmental durability, and long-term signal reliability. - 04Made in America
Every component is manufactured domestically at our St. Petersburg, Florida facility for strict quality control.
Applications
Radar Systems
Compact signal routing for phased array and tracking radar systems requiring precise waveguide layouts.
Satellite Ground Stations
Connects feed horns and LNBs in satellite earth station waveguide assemblies.
Electronic Warfare
Essential for routing signals in space-constrained EW receiver and jammer assemblies.
Test Fixtures
Enables flexible waveguide routing in laboratory test benches and calibration setups.
More RF Components
Frequently Asked Questions
What is an E-plane waveguide bend?+
An E-plane bend curves the waveguide along its wider dimension (the E-field plane). This redirects the signal path while maintaining the waveguide's electromagnetic mode structure. Standard configurations include 90-degree bends.
What bend angles are available?+
RF Essentials offers standard 90-degree E-plane bends. Custom bend angles and radii are available upon request for specialized system integration requirements.
How do E-plane bends differ from H-plane bends?+
E-plane bends curve along the wider dimension of the waveguide (electric field plane), while H-plane bends curve along the narrower dimension (magnetic field plane). The choice depends on the physical orientation needed in your waveguide assembly.
